Belt Sway Switch

Belt-sway switch is generally mounted on both side, preferably at about every 30 meters s and near the edge of the conveyor belt. A small clearance is allowed between contact roller and the belt edge to allow the normal running of the belt with acceptable swaying. When swaying exceeds normal limit, the belt edge pushes the contact roller, which drives the switch and operates the contacts. The switch resets automatically when the belt resumes normal running.

• Reset : Auto / Spring Reset Type
• Enclosure: Weatherproof, field mounting Type, IP 65 Cast Al, Cast Iron, epoxy painted
• colour : Light gray (standard) other
• Output Contacts : 1 NO + 1 NC / 2 NO + 2 NC / 2 NC / 4 NC
• Contact Rating for standard models: 16 Amp resistive at 440 VAC

Q: What is the function of the Belt Sway Switch?

A: The Belt Sway Switch protects against damage due to belt sway.

Q: What is the rated voltage of the Belt Sway Switch?

A: The rated voltage of the Belt Sway Switch is 230 Volt (V).

Q: What is the color of the Belt Sway Switch?

A: The Belt Sway Switch comes in blue color.

Q: What is the warranty period for the Belt Sway Switch?

A: The Belt Sway Switch comes with a 1-year warranty.

Q: What is the weight of the Belt Sway Switch?

A: The Belt Sway Switch weighs 3 kilograms (kg).

Q: Where is the Belt Sway Switch usually applied?

A: The Belt Sway Switch is usually applied in industrial settings.

Q: Can the Belt Sway Switch be used for other applications besides industrial use?

A: No, the Belt Sway Switch is specifically designed for industrial use only.
