Damaged Belt Detector / Belt Tear Monitor
ROPE TYPE: Series DBD R:
Conveyor belts are subject to wear and tear during operation.Repairs like vulcanization and splicing have to be carried out from time to time. In large conveyor plants,impending belt damages are not always noticed in advance. SMARTsaa make Damaged Belt Detector Series: DBD enables the following belt damages to be detected at an early stage.
- Parts of the belt have come off in shreds.
- Steel ropes stand off from the belt.
- Belt edges are torn.
- Facing of repair point have come off.
- Slices are defective.
- Sharp object protruding through the belt fabric.
Damaged Belt Detector is to be mounted in pairs, positioned on either side of the belt. The units are connected by two spans of special PVC coated cable. One end of the cable mounts permanently to a support bracket and the other end is connected to a spring loaded ball located in a DBD unit. The switch gets actuated when an object or broken belt surface sweeps away one or both cables pulling spring loaded ball out of socket.
SPECIFICATION OF SERIES DBD R
- Enclosure: Heavy Duty Cast Al, IP 65
- Output: 2 NO + 2 NC contact rated for 10 Amp resistive at 230 V
- AC supplied with tripping cable length of 3 Meter
- Supplied with bracket
- Note: As to protect the conveyor for entire cross section, two
- damaged belt detectors are required.
- We therefore recommend to process your order in pairs ( 2 Nos).
| Color |
Light Grey |
| Material |
Cast Al |
| Usage/Application |
Industrial |
| Model Name/Number |
DBD R |
| Grip Type |
Ball and Catch |
| Brand |
SMARTsaa |
| Features |
Heavy duty, simple to install |
| Ip Rating |
IP 65 |
| Country of Origin |
Made in India |
FAQs of Damaged Belt Detector Rope Type Safety Switches:
Q: What is the weight of Damaged Belt Detector Rope Type Safety Switches?
A: The weight of Damaged Belt Detector Rope Type Safety Switches is 3 kilograms (kg).
Q: What is the function of Damaged Belt Detector Rope Type Safety Switches?
A: The function of Damaged Belt Detector Rope Type Safety Switches is to detect belt damage or belt tear.
Q: What is the rated voltage of Damaged Belt Detector Rope Type Safety Switches?
A: The rated voltage of Damaged Belt Detector Rope Type Safety Switches is 230 Volt (V).
Q: What is the output of Damaged Belt Detector Rope Type Safety Switches?
A: The output of Damaged Belt Detector Rope Type Safety Switches is 2 C/O.
Q: What is the warranty period for Damaged Belt Detector Rope Type Safety Switches?
A: The warranty period for Damaged Belt Detector Rope Type Safety Switches is 1 year.
Q: Where can I apply Damaged Belt Detector Rope Type Safety Switches?
A: You can apply Damaged Belt Detector Rope Type Safety Switches in industrial applications.
Q: What is the color of Damaged Belt Detector Rope Type Safety Switches?
A: The color of Damaged Belt Detector Rope Type Safety Switches is light grey.
